Xiaomi XRING O1 Die Shot Reveals Details of 10-Core U, 6-Core NPU and More i3m6i

Xiaomi unveiled the XRING O1 on Thursday as its first in-house chipset for the Xiaomi 15S Pro, and details of the chipset have now surfaced online. It is a 3nm chip that is built using Taiwan Semiconductor Manufacturing Company's (TSMC) advanced N3E process technology, which was also used by Apple, MediaTek and Qualcomm for their own 3nm processors. The XRING O1 will be avalable on smartphones in China, and it features a 10-core U, a 6-core NPU, and a 16-core GPU.

XRING O1 Features 10-Core U and 6-Core NPU 5n5j2y

A die shot of the new XRING O1 posted by Kurnal (@Kurnalsalts) on X (formerly Twitter) gives us a closer look at the new chipset from Xiaomi (via Notebookcheck). According to the , the new Xiaomi XRING O1 has a die area of 114.7 sq mm (10.8×10.6mm) and the components take up 109.5 sq mm of space.

As a result, Xiaomi's 3nm SoC is as small as rival flagship chipsets, which are also built using TSMC's N3E process technology. The die shot also reveals the layout of various components, including the U, GPU, and NPU cores on the new chip.

The new XRING O1 chip from Xiaomi is equipped with a 10-core U that comprises two Arm Cortex-X925 cores (3.9GHz), six Cortex-A725 cores (up to 3.4GHz), and two Cortex-A520 (1.8GHz) cores. It has a 16-core Arm Immortalis-G925 MP16 GPU and a 6-core NPU. The U and NPU are both equipped with a 16MB cache.

The die show also reveals that the XRING O1 will offer for LPDDR5T RAM at 9,600Mbps. It also features a sensor hub and an unidentified encryption core. The chip doesn't reveal the presence of a modem, which means that the Xiaomi 15S Pro will be equipped with another modem.

According to recent benchmark results for the XRING O1 suggested that the chip could offer performance that is on par with the flagship Snapdragon 8 Elite from Qualcomm. It remains to be seen whether Xiaomi incorporates the XRING O1 chip on more smartphone models in the future.
